Professional manufacturer of Rotary Dryer

Professional manufacturer of Rotary Dryer

Professional manufacturer of Rotary Dryer
Professional manufacturer of Rotary Dryer

Large Image :  Professional manufacturer of Rotary Dryer Get Best Price

Product Details:
Place of Origin: Henan Province, China
Brand Name: Sinolion
Certification: ISO
Model Number: 1200*15000
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: 7000USD-15000USD
Packaging Details: standard container
Delivery Time: 20 days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 10sets per month
Detailed Product Description

Professional manufacturer of Rotary Dryer:

Specifications

Yonghua iron ore drying machine
1.moisture of raw material can be reduced to below 5%
2.coal, oil, gas can be used as fuel

Yonghua rotary dryer introduction

1. Structure of rotary drier

Drier also named as Drying Machine and Rotary Drier.Drier is mainly consist of rotary body, raw material feeding plate, driving and supporting device, etc

2. Application of rotary drier

Rotary drier is used to dry slag, clay, limestone, It is mainly used for cement, chemical, metallurgical, building materials industries.

3. Working principle of rotary drier

Its principle of operation: the raw material plate which is arranged reasonably with changeable angles in order, throws moisture materials into the rotary cylinder. Then water will be separated from the materials by hot air-flow and changed into vapour to be discharged into the atmosphere. Then the materials would be dried.

4. Whole set rotary dryer equipments

feeder, bucket elevator, rotary dryer,dust collector, heat resource

5. Technical Parameter:



Model

The Diameter

(mm)

The  Length

(m)

Slope(°)

Speed

(r/min)

Power

(kw)

Volume

(m3)

0.6×8-12

600

8-12

3-5

8

4

2.26

0.8×10-10

800

10-12

3-5

7.2

4

5.02

1.0×10-12

1000

10-12

3-5

6.73

5.5

7.85

1.2×12-18

1200

12-18

3-5

5.8

11-15

13.31

1.5×12-18

1500

12-18

3-5

4.8

15-22

21.2

1.8×12-18

1800

12-18

3-5

3.2

185-30

48.22

2.2×12-22

2200

12-22

3-5

3

22-30

70.43

2.8×15-24

2800

15-24

3-5

2.59

30-55

147.8
