High Efficient Mine Ore Processing Ball Mill Machine

High Efficient Mine Ore Processing Ball Mill Machine

High Efficient Mine Ore Processing Ball Mill Machine
High Efficient Mine Ore Processing Ball Mill Machine High Efficient Mine Ore Processing Ball Mill Machine High Efficient Mine Ore Processing Ball Mill Machine

Large Image :  High Efficient Mine Ore Processing Ball Mill Machine Get Best Price

Product Details:
Place of Origin: Henan, China
Brand Name: Sinolion
Certification: CE,ISO
Model Number: 1500*4500
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: USD5000-15000/set
Packaging Details: wooden case, standard container
Delivery Time: 10-15 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10 sets per month
Detailed Product Description
Warranty: 1 Year Application: Powder,Medicine Processing,Chemicals Processing
Voltage: 220V/380V,220V,380V,Customized Material: Sus304/316L,stainless Steel430/304/316L,fluoroplastic Alloy
Condition: New After-sales Service Provided: Engineers Available To Service Machinery Overseas,Video Technical Support,Online Support,Overseas Service Center Available,No After-sales Service

High Efficient Mine Ore Processing Ball Mill Machine



Ball mill application

Ball mill is an efficient tool for grinding many materials into fine powder. The Ball Mill is used to grind many kinds of mine and other materials, or to select the mine. It is widely used in building material, chemical industry, etc.There are two ways of ball mill grinding: the dry way and the wet way. It can be divided into tabular type and flowing type according to different expelling mine. our ball mill prices is reasonable base on the good quality, we support the Trade Assurance Online Order.

High Efficient Mine Ore Processing Ball Mill Machine 0

Ball mill strucuture



Ball mill is made up of feedisng part, discharging part, gyre part, transmission part, (decelerator, small transmission gear, motor, electrical control) and so on.



The hollow axis adopts the cast steel and the lining can replace, the rotating big gear processes in the way of casting rolling gear. The barrel body is wearable well and bears wearable scaleboard. This machine run steadily and works reliably.

Ball mill Working Principle
The ball mill is a horizontal rotating device transmitted by the outer gear. The materials are transferred to the grinding chamber through the quill shaft uniformly. There are ladder liner and ripple liner and different specifications of steel balls in the chamber. The centrifugal force caused by rotation of barrel brings the steel balls to a certain height and impact and grind the materials. The ground materials are discharged through the discharging board thus the grinding process is finished.

High Efficient Mine Ore Processing Ball Mill Machine 1

Ball Mill Featurers:

1.Large application range, simple structure and convenient maintenance;

2.Large capacity and continuous work are very obvious;

3.Barrel lining and grinding media can apply various abrasive materials;

4.Installation and adjustment are very convenient and easy to be operated.

High Efficient Mine Ore Processing Ball Mill Machine 2High Efficient Mine Ore Processing Ball Mill Machine 3

High Efficient Mine Ore Processing Ball Mill Machine 4

High Efficient Mine Ore Processing Ball Mill Machine 5

Ball mill parameters

Model shell rotation speed (r/min) Ball load (t) Feeding size(mm) Discharging size(mm) Capacity (t/h) Power (KW) Weight (T)
900×1800 38 1.5 ≤20 0.075 -0.89 0.65 -2 18.5 3.6
900×2100 38 1.3-1.4 ≤15 0.075 -0.83 0.7-3.5 18.5 3.9
900×3000 38 2.7 ≤20 0.075 -0.89 1.1-3.5 22 4.5
1200×2400 32 3.8 ≤25 0.0745-0.6 1.5-4.8 30 11.5
1200×2800 32 3.3-3.5 ≤25 0.0745-0.6 2-6 30 12.8
1200×3000 36 3.5 ≤25 0.074-0.4 1.6-5 37 13
1200×4500 32 7 ≤25 0.074 -0.4 1.6-5.8 45 13.8
1500×3000 27 8 ≤25 0.074 -0.4 2-5 75 17
1500 ×3500 27 6.75-6.4 ≤25 0.075 -0.4 3-7 75 17.5
1500×4500 27 14 ≤25 0.074 -0.4 3.5-12 110 21
1500×5700 27 15 ≤25 0.074 -0.4 3.5-8 115 24.7
1830×3000 24 18 ≤25 0.074 -0.4 4-10 130 28
1800×3600 24 10.6-11.35 ≤25 0.075 -0.4 5-22 130 30
1830*4500 25.4 15 <=25 0.074-0.4 4.5-12 155 32
1830×6400 24.1 21 ≤25 0.074~0.4 6.5-15 210 34
1830×7000 24 25 ≤25 0.074 -0.4 7.5-17 210 36
2100×3000 23.7 15 ≤25 0.074-0.4 6.5-36 155 39
2100×3600 22 14-15.2 ≤25 0.075 -0.4 15-36 370 42
2100×4500 23.7 24 ≤25 0.074-0.4 8-43 245 43.8
2100×7000 23.7 26 ≤25 0.074-0.4 8-48 280 56.6
2200×4500 21.5 27 ≤25 0.074-0.4 9-45 280 45.5
2200×5500 21 30 ≤25 0.074 -0.4 10-20 210 48.5
2200×6500 21 31 ≤25 0.074 -0.4 14-26 380 52.8
2200*7000 21.7 35 <=25 0.074-0.4 15-28 380 54
2200×7500 21 33 ≤25 0.074 -0.4 16-29 380 56
2400×3000 20.6 15.5-16.6 ≤25 0.075 -0.4 22-24 245 59
2400×4500 21 30 ≤25 0.074 -0.4 8.5-60 380 65
2700×3600 20.6 39 ≤25 0.074 -0.4 12-70 400 91.3
2700×4000 20.7 40 ≤25 0.074 -0.4 12-80 400 94
2700×4500 20.7 48 ≤25 0.074 -0.4 12-90 430 102
3200×4500 18 65 ≤25 0.075
-0.4
according to the technology 800 137



About our company and service

_____________________________________________________________________________



Yonghua equipment can provide turkey service for customers, such as engineering consultation, engineering design, equipment manufacturing, packing & transportation, installation & commissioning personnel training etc.



About Spare Parts

Yonghua equipment will be dedicated to provide our customers with genuine spare parts with high quality. With our technological advice, the life cycle of your machine can be prolonged and sustained significantly with high effectiveness.



About Training

Yonghua equipemnt could offer excellent facilities and comfortable environment and training services to different customers. The training should include product training, safety training, operation training, maintenance know-how, technical know-how training, and regulations training, etc. All of the training is customized to fulfill every customer’s expectations. Training programs can be conducted in our workshop, or at customer’s site.



About Installation and Commissioning

Yonghua equipment are able to guide the overall installation of whole set production line, including crushing production line and cement equipment production line, etc., which will allow you to start the normal operation of equipment immediately. After installation,we will make inspection of the whole machine commissioning and operation condition and provide you testing data report of installation.

Contact us:

You are welcome to our company for visiting and business cooperation. We will provide you the best services and most favorable ball mill price. For more introduction, please contact with me !
