Product Details:
Payment & Shipping Terms:
|
Codition: | New | Motor Power: | 30kw |
---|---|---|---|
Weight: | 1200kgs | Capacity: | 2-3t/h |
Cutter Head Diameter: | 800mm |
Brief introduction of wood crusher :
It is a new style and widely used machine. Its widely used in all kinds of crop stalk, cotton firewood, straw, clover, peanuts shells, cotton seed fur, etc. This series of machine have advantages of compact structure, strong and durable, safe and reliable, easy operation, lower noise and vibration, high efficiency and low energy consumption, etc. And the spare part of the machine completely adopt quality material, outsourcing parts adopting domestic optimal product,the whole machine's quality is reliable, long-lived.
Wood crusher working principle:
Wood crusher is the special equipment for producing wood chips. The timber is sent into the feeding port, as long as the wood touch the peel and cut blade, the wood begin to be peeled and cut at the high speed rotating with the cutter head, and then the wooden pieces in the cutting room are sent out with the faster-moving air produced by the blade movement.The whole chipping process is finished.
Structure of wood crusher :
Wood crusher is mainly made up of coupling bottom frame and motor,feeding port, the cutter head, peel and cut blade and electronic control. Wood crusher can adjust the peel and cut blade according to need in order to produce the different specifications and thickness of wood.
Features & Benefits of wood crusher :
1. Wood crusher has reasonable design and stable structure
2. . Wood crusher has highly eco-friendly and saves energy
3. The wood chipper machine has low operation cost
4. Reliable and safe lubrication system.
Application of the wood crusher :
Wood crusher is used to cut the wood log and branches into chips, that is used for material of man-made wood board
Wood crusher is suitable branch and many kinds of waste wood, all can be cut into chip, which size is about 30mm
Main technical parameter of wood crusher :
Type |
800 |
950 |
1100 |
1210 |
1410 |
Cutter head diameter (mm) |
800 |
950 |
1100 |
1210 |
1410 |
Revolving speed of cutter head(r/m) |
960 |
960 |
960 |
960 |
960 |
Number of the blade(piece) |
4 |
4 |
4 |
4 |
4 |
Feeding way |
slope |
slope |
slope |
slope |
slope |
Discharge method |
upwards |
upwards |
upwards |
upwards |
upwards |
power equipment (kw) |
30 |
37 |
45 |
75 |
90 |
Capacity( t/h) |
3-6 |
6-8 |
8-10 |
10-13 |
13-16 |
Max. cutting diameter(cm) |
20 |
25 |
30 |
35 |
40 |
