Plate hammers vertical shaft quarry stone heavy new equipment compound crusher
1 set
MOQ
USD 2500-5000 per set
Price
Plate hammers vertical shaft quarry stone heavy new equipment compound crusher
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Henan
Brand Name: Berno
Certification: CE,ISO
Model Number: PFL600, PFL800, PFL1000, PFL1250, PFL1500
Payment & Shipping Terms
Packaging Details: wooden case, container
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 20n sets per month
Specifications
Color: Customized
Capacity: 5-100t/h
Input Size: <100mm
Outlet Size: <5mm
Main Shaft Speed: 1000r/min
Motor Power: 11-110kw
Condition: New
Weight: 1-30t
Warranty: 1 Year
Dimension(l*w*h): According To The Machine Type
After-sales Service Provided: Field Maintenance And Repair Service,Online Support,Video Technical Support,Field Installation
Motor Type: AC Motor
Application: Mining,coal,construction,ore,stone
Color: Or Customized Color
Test&installation: Professional Engineer Assigned,Engineer's Guide
Spare Parts Supply: Will Supply Any Time
Installation: Under Engineer's Guide,engineer Guide On Site,under The Guidance Of Engineer,Professional Engineers Assigned
The Machines Classification: Stone Crushing Machine
After-sale Service: 24 Hours Service Hotline
Product Description

Plate hammers vertical shaft quarry stone heavy new equipment compound crusher



Description of Vertical combination crusher

The vertical combination crusher can be used as a vertical crusher, coal crusher, stone crusher apply to crushing industry
Vertical composite crusher, synthesis of domestic and foreign similar technology crusher, the main technical parameter optimization is meticulous research and development of a new equipment, mainly used for small and medium-sized cement clinker finely homework, unripe, but also be used for iron ore, sandstone, gypsum, dolomite, coal, gold, serpentine, blast furnace slags, gangue, phosphate rock medium hardness materials, compressive strength does not exceed 140 mpa, humidity does not exceed 15%.



Plate hammers vertical shaft quarry stone heavy new equipment compound crusher 0



Features of Vertical Combination Crusher:

1. It has simple and reasonable structure and low running costs;
2. Large crushing ratio and energy saving;
3. It has the function of fine crushing and coarse grinding;
4. The moisture content of materials has little impact on the crusher.

Plate hammers vertical shaft quarry stone heavy new equipment compound crusher 1



Main technical parameters of Vertical Combination Crusher:

Model PFL-800 PFL-1000 PFL-1250 PFL-1500 PFL-1750 PFL-2000

Shaft speed

(r/min)



1000 750 530 495 424 370

Input size(mm)



<50 <120 <150 <120 <120 <220

Output size(mm)



<3-5,60-90% <3-5,60-90% <3-5,60-90% <3-5,60-90% <3-5,60-90% <3-5,60-90%

Capacity

(t/h)



10-20 20-45 40-70 70-100 130-190 150-220

Power(kw)



15-22 37-55 55-75 132 160 185

Dimensions(mm)



2100*1200*1700 2600*1400*1900 2800*1600*2100 3100*1900*2200 3710*2360*2390

4100*2660*

2620



Weight (kg)

4300 6200 8500 13700 20200 24500

double stage crusher and compoud crusher.pdf

Working Principle of vertical combination crusher

Raw material is fed from the top of combination crusher, and fall into the rotating impeller at a high speed to be crushed. As other materials simultaneously fall around the rotating impeller, the two kinds of materials join together and are crushed by each other. The materials are crushed many times in and around the impeller of combination crusher, and are finally discharged beneath the machine. Via a closed loop, controlled by screening equipment, the product achieves its required final size.

Our Services

♦ Pre-sale services: Passion &thoughtful

We provide you with the prophase plan, process flow design and manufacturer equipment according to your special demand.

♦ Sale services: Oversea Technicians

Oversea technicians will be sent to the jobsite for guiding the installation training operators and finishing the check and accept together with you.

♦ After-sale services: Faithfulness

One year warrantee to make sure your machine runs consistently. We always keep certain inventory level of spare parts, which means the replacements can be shipped to you right away.



Plate hammers vertical shaft quarry stone heavy new equipment compound crusher 2

double stage crusher and compoud crusher.pdf

Plate hammers vertical shaft quarry stone heavy new equipment compound crusher 3
