PC600*400 rock stone energy saving mining hammer crusher machinery

PC600*400 rock stone energy saving mining hammer crusher machinery

PC600*400 rock stone energy saving mining hammer crusher machinery
PC600*400 rock stone energy saving mining hammer crusher machinery PC600*400 rock stone energy saving mining hammer crusher machinery PC600*400 rock stone energy saving mining hammer crusher machinery PC600*400 rock stone energy saving mining hammer crusher machinery

Large Image :  PC600*400 rock stone energy saving mining hammer crusher machinery Get Best Price

Product Details:
Place of Origin: Henan, China
Brand Name: Sinolion
Certification: ISO
Model Number: PC400*300, PC600*400,PC800*600, PC1000*800, PC1000*1000, PC1250*1250
Payment & Shipping Terms:
Minimum Order Quantity: 1sets
Price: 2000-8000USD/SET
Packaging Details: container, wooden case
Delivery Time: 15days
Payment Terms: T/T
Supply Ability: 20sets
Detailed Product Description
Condition: New Weight: 1-30t
Warranty: 1 Year Dimension(l*w*h): According To The Machine Type
After-sales Service Provided: Engineers Available To Service Machinery Overseas,Field Maintenance And Repair Service,Online Support,Video Technical Support,Field Installation Type: Hammer Crusher
Motor Type: AC Motor Capacity(t/h): 5-200t/h
Application: Mining,coal,construction,ore,stone Color: Customizable
Test&installation: Professional Engineer Assigned,Engineer's Guide Spare Parts Supply: Lifelong Time
Installation: Under Engineer's Guide,engineer Guide On Site Max Feeding Size: 125mm
After-sale Service: For Whole Using Life

PC600*400 rock stone energy saving mining hammer crusher machinery 0

PC600*400 rock stone energy saving mining hammer crusher machinery





Product Description

Hammer crusher is developed and applied widely in mines, quarries, road construction, building material, highway, railway, water conservancy and other industrial. The product specification is complete, the feed size from 150-1500 mm, hammer crusher crushing materials of compressive strength of up to 300Mpa, it is a complete set of broken lines in the first choice of primary crushing equipment.

PC600*400 rock stone energy saving mining hammer crusher machinery 1
working principle of  Hammer Crusher
In the stone crusher plant, the motor drives the rotor rotate at a high speed through the belt, and on the rotor there are series hammers. When the materials get into the working area of hammers, the rotating hammers with high rotation speed are crushing them, the products which are crushed to meet the required size can be discharged by the outlet and become the final products, the large size products are brought back to the crushing area by the hammers for being recrushed until they reached the required size.

raw materail:

PC600*400 rock stone energy saving mining hammer crusher machinery 2
Advantages of  Hammer Crusher :

1. It can crush the stone independently, and it doesn't need the second crusher to better the materials, so it can reduce the user's cost by 35%. Low power,low investment.

2. It can crush the wet stone, that is to say, you can wet the stone when crushing it to reduce the dust pollution, and keep the workers health and the good environment.

3. It has durable hammer, especially the PCZ series heavy hammer crusher, it is more durable than the jaw crusher and imact crusher combination and the standard hammer crusher. It use the alloy hammer, and cast steel parts to guarantee the function and its life.

4. We have many types, the capacity ranges from 50t/h to 800t/h, to meet ht evarious requirements.

PC600*400 rock stone energy saving mining hammer crusher machinery 3
Technical parameter of  Hammer Crusher


Model Feeding size Discharging size capacity Motor power weight
PC400×300 ≤100mm ≤10mm 5-10t/h   11kw    0.8t
PC600×400 ≤120mm ≤15mm 10-25t/h   18.5kw    1.5t
PC800×600 ≤120mm ≤15mm 20-35t/h   55kw     3.1t
PC1000×800 ≤200mm ≤15mm 20-40t/h   90kw     7.9t
PC1000×1000 ≤200mm ≤15mm 30-70t/h   132kw     8.5t
PC1250×1250 ≤250mm ≤25mm 50-100t/h   185kw     10t
PC1300×1200 ≤250mm ≤25mm 60-150t/h   240kw      13t
PC1400×1400 ≤280mm ≤30mm 120-170t/h   280kw      16t
PC1600×1600 ≤350mm ≤30mm 200-280t/h   450kw       19t
Product features


1. Easy installation and maintenance.
2. Developed structure and long service life.
3. Difficult deformation with high strength.
4. Unblocked material flow and large production capacity.
5. Smooth and reliable performance.
6. Low consumption of spare parts and low maintenance costs.

 PC600*400 rock stone energy saving mining hammer crusher machinery 4

♥Packing & Delivery
♥Standard export packing,
♥The loading port is Qingdao Port, also can be requested by customer. We have superior cargo agent to arrange the sea shipment for each client, competitive price, secure transportation.

♥All products will be processed to be rustproof and moisture proof before delivery.
♥20GP container or 40GP container Equipment is packed with plastic wrap or steel case, depends on machine weight.
♥Motor is packed with steel case or wooden case.
♥Control panel is packed with wooden case or Plastic packaging
♥Loading container in factory.

PC600*400 rock stone energy saving mining hammer crusher machinery 5



After Sales Service

Pre-sales service: We provide you with the prophase plan, process flow design and manufacturer equipment according to your special demand.
Sales service: Send technicians to the jobsite guiding the installation and adjustment, training operators and finishing the check and accept together with you.
After-sales service: To establish long term friendship, we will reg-ularly pay return visit to customers. Supplying technique, building design, instruction, installation and debugging for free.
Lifelong service: One year warranty to make sure your machine runs constantly.Always offer lifelong service and provide spare parts for a long term.

How long is the guarantee?
All of our products are guaranteed for one year. If products quality is not consistent with the description as we described or the promise before you place order, we promise 100% refund.

PC600*400 rock stone energy saving mining hammer crusher machinery 6

FAQ

Question 1: What's the delivery time after I pay the deposit ?
Answer: We will delivery the goods within 15-25 working days after receipt of the prepayment.

Question 2: Is mineral samples analysis available?
Answer: Sure, we supply samples analysis service for free. After the testing, we will give you the reasonable flow chart, suitable solution and equipment selection.

Question 3: Do you have client in my country?
Answer: Our products have exported to Malaysia, Indonesia, the Philippines, Vietnam, Myanmar, Korea, Singapore, Thailand, Mongolia, Ghana, Sudan, Serbia, Kazakhstan, Canada, Nigeria, Australia, Chile, Brazil, Columbia, Ecuador, Peru, Bolivia, etc

Question 4: How long of your machine quality guarantee terms ?
Answer: Quality guarantee time is one year(wearing parts excluded).

About our company

Zhengzhou Berno Machinery Co., Ltd. is a high-tech Company which professional manufacturing the production of briquette production line equipment and mining machinery.
After 30years of development, Sinolion is now setting up branches, integrating engineering, trade, research and development,
Zhengzhou Berno have modern standard workshops, as well as advanced technology and testing equipment. Extensively cooperating with coal research institutions and other research departments, Now, 10,000-300,000 tons briquette production lines are renowned in domestic and foreign markets, Our products have been exported to Indonesia, Kazakhstan, Vietnam, North Korea, Egypt and other countries and regions. It is ideal equipment for briquetting mine power in the world market.
We provides space planning and design, equipment installation and commissioning support.

PC600*400 rock stone energy saving mining hammer crusher machinery 7



PC600*400 rock stone energy saving mining hammer crusher machinery 8
