Quality Reliable Iron Ore model PFL1000 Vertical Combination Crusher Machine

Quality Reliable Iron Ore model PFL1000 Vertical Combination Crusher Machine

Quality Reliable Iron Ore model PFL1000 Vertical Combination Crusher Machine
Quality Reliable Iron Ore model PFL1000 Vertical Combination Crusher Machine Quality Reliable Iron Ore model PFL1000 Vertical Combination Crusher Machine Quality Reliable Iron Ore model PFL1000 Vertical Combination Crusher Machine Quality Reliable Iron Ore model PFL1000 Vertical Combination Crusher Machine Quality Reliable Iron Ore model PFL1000 Vertical Combination Crusher Machine Quality Reliable Iron Ore model PFL1000 Vertical Combination Crusher Machine

Large Image :  Quality Reliable Iron Ore model PFL1000 Vertical Combination Crusher Machine Get Best Price

Product Details:
Place of Origin: Henan Province, China
Brand Name: Sinolion
Certification: ISO
Model Number: PFL600, PFL800, PFL1000, PFL1250, PFL1500
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: 3000-8000
Packaging Details: standard container or wooden case
Delivery Time: in stock
Payment Terms: T/T, L/C, Western Union
Supply Ability: 20 set per month
Detailed Product Description
Condition: New Weight: 1-30t
Warranty: 1 Year Dimension(l*w*h): According To The Machine Type
After-sales Service Provided: Engineers Available To Service Machinery Overseas,Field Maintenance And Repair Service,Online Support,Video Technical Support,Field Installation Motor Type: AC Motor
Capacity(t/h): 15-650TPH Application: Mining,coal,construction,ore,stone
Color: Iron Grey,red,or Customized Color Power(w): 40-132 Kw
Test&installation: Professional Engineer Assigned,Engineer's Guide Spare Parts Supply: Will Supply Any Time,Lifelong Time,For Whole Year,For Whole Using Life,Anytime
Installation: Under Engineer's Guide,engineer Guide On Site,under The Guidance Of Engineer,Professional Engineers Assigned The Machines Classification: Stone Crushing Machine
After-sale Service: 12 Months

Quality Reliable Iron Ore model PFL1000 Vertical Combination Crusher Machine 0

Quality Reliable Iron Ore model PFL1000 Vertical Combination Crusher Machine



1.Introduction of Vertical Combination Crusher:
This vertical combination crusher also named compound Crusher is widely used in all kinds of ores, cement, refractories, alumina clinker, glass raw materials and high hard, hard materials, fine in the field. In the mechanism building sand, stone and breaking of metallurgical slag is more widespread use, compared with other types of crusher production with high efficiency.

Quality Reliable Iron Ore model PFL1000 Vertical Combination Crusher Machine 1

The features of Vertical Combination Crusher:
1.The production capacity is big.
2.The crushing ration is high and the power consumption is low.
3.The stability is good and machine running is stable.
4.The maintenance is simple.

Vertical Combination Crusher's crushing ratio is big. And the biggest crushing ratio can get to the discharging granularity and can be adjusted freely. The plate hammer and lining board wearing cannot have effect on the crushing ratio. There is no sieve bar. The machine cannot be blocked when it crushes the materiel with high humidity and mud percetage. It adopts elastic adjustment structure. If the material which cannot be broken gets into the machine, it can be discharged automatically, so the machine cannot be damaged. The bearing is fixed horizontally and its usage life is long. This machine’s rotor is special. The rotor body hardly wear when the machine crushes the materiel.

Our vertical combination crusher are suitable for primary and secondary crushing, with low power consumption and easy maintenance. Every feature of these machines has been carefully designed to provide superior quality and performance.and chemical industry.

Specifications of Combination Crusher

Model



Feeding size
(mm)



Output size
(mm)



Capacity
(t/h)



Rotating speed of main shaft
(r/min)



Power
(kw)



Overall size
(mm)

PFL-800

<100

<3-5 60-90%

10-20

934

22

2100×1200×1700

PFL-1000

<120

<3-5 60-90%

20-40

769

37

2600×1400×1900

PFL-1250

<150

<3-5 60-90%

40-70

530

75

2800×1600×1000

PFL-1500

<180

<3-5 60-90%

70-100

495

132

3100×1900×2200

PFL-1750

<200

<3-5 60-90%

130-190

424

160

3710×2360×2390

PFL-2000

<220

<3-5 60-90%

100-160

370

185

4100×2660×2620

Advantages of combination crusher

1.) Simple structure low operation cost
2.) High broken rate
3.) Low noise
4.) Maintenance easy

Quality Reliable Iron Ore model PFL1000 Vertical Combination Crusher Machine 2

Quality Reliable Iron Ore model PFL1000 Vertical Combination Crusher Machine 3
