I. Screw Sand Washing Machine Description:
Screw Sand washing machine is of high efficiency and has the features of reasonable structure, high capacity and low consumption. Sand washing machine can make final products free from dirt and impurities and reduce the high quality sand loss. Sand washing machine is on behalf of the new technique compared with the same equipment in other companies.
II. Screw Sand Washing Machine Application:
Screw Sand washing machine is used to remove the dust in sand. Sand washer aims at improving the quality of sand. The materials include the required gravel in building-site, gravel factories, hydropower station and concrete dam site, post and electric pole factory, casting-70 sand, glass factory's quartz sand and refilling pressure sand. Sand washing machine is widely used for cleaning materials in the following industries: quarry, minerals, building materials, transportation, chemical industry, water conservancy and hydropower, cement mixture station and so on.
III. Features of Screw Sand washing machine:
•1.low price and high productivity
•2.easy to adjust, easy maintenance and stable and long span life
•3.reliable operation, thyristor-control, durable construction
•4.well-proven performation for many years, no pollution
IV. Technical parameters of screw sand washing machine:
Model |
Impeller dia. mm |
Feeding size(mm) |
Capacity (t/h) |
Power (KW) |
Weight (kg) |
Dimension (mm) |
XS 2615 |
2600×1500 |
≤10 |
30-80 |
7.5 |
2700 |
3320×2200×2670 |
XS2900 |
2900×1000 |
≤10 |
50-100 |
7.5 |
8100 |
3820×2640×3200 |
XS3016 |
3000×1600 |
≤10 |
80-160 |
18.5 |
4300 |
4500×3206×3480 |
XS3500 |
3500×1000 |
≤10 |
120-600 |
11 |
9900 |
4420×2930×3800 |
