Energy saving Cow dung, chicken dung, sheep dung dehydration drum dryer
1set
MOQ
USD6000-USD20000
Price
Energy saving Cow dung, chicken dung, sheep dung dehydration drum dryer
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Henan Province, China
Brand Name: Berno
Certification: ISO, SGS
Model Number: 0.8*8.0m, 1.0*10m, 1.2*10m,1.5*15m, 1.5*18m, 1.8*18m, 2.2*20m, 2.4*20m, 3.0*28m
Payment & Shipping Terms
Packaging Details: standard container
Delivery Time: 15 days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 20 set per month
port: Qingdao or Shanghai
Specifications
Capacity: 0.5-50t/h
Motor Power: 5.5-110kw
Color: Red, Customized
Voltage: 220V 50HZ,220v/380v,380v,380V/220V,380V/50HZ
Power(w): Based
Condition: New
Weight: 2.9-104.9t
Warranty: 1 Year
Type: Vacuum Drying Equipment,Rotary Drying Equipment,Spray Drying Equipment
After-sales Service Provided: Engineers Available To Service Machinery Overseas,Video Technical Support,Online Support
Application: Food Processing,Medicine Processing,Chemicals Processing,Pharmaceutical
Name: Continuous Dehydrator System Alfalfa Drying Equipment,Rotary Dryer Price,creative Lab Vacuum Drying Oven Equipment With Ce Certificated,rotary Drying Equipment
Product Name: Big Capacity Elephant Grass Rotary Drum Dryer Drying Equipment
Installation: Under Technician's Guidance,Engineer Guide
Color: Customized
Heating Source: Electricity / Coal / Natural Gas / Diesel
Material: SS304/SS316L,Q235
Raw Material: Carbon Steel
Usage: Reduce Material's Moisture
Product Description

Energy saving Cow dung, chicken dung, sheep dung dehydration drum dryer







Rotary Dryer Introduction:

Rotary dryer is widely used to dry materials in industries like cement, mine, construction, chemical, food, compound fertilizer, etc. Thermocouples are installed in feeding and discharging units to control temperature. Temperature change of the dryer also can be indicated by the thermometer, which is convenient for temperature control inside the dryer ( it is usually 250-350℃).

Energy saving Cow dung, chicken dung, sheep dung dehydration drum dryer 0

Application of rotary dryer



Powder & particle: Sands, limestone, stones, clay, mineral filter cake, coal, iron sulphate, filter cakes, fly ash, gypsum etc.

Damp and sticky material: Coal slime, sewage sludge, bentonite, Kaolin etc.

Corrosive material: Distillers ‘grains, Fertilizer, animal dung, slag etc.

Biomass material: Sawdust, wood chips etc.

Energy saving Cow dung, chicken dung, sheep dung dehydration drum dryer 1



Specifications

new designed high quality and durable competitive rotary dryer:
1.Used for coal,cement,ore drying
2.Fast delivery
3.OEM

Energy saving Cow dung, chicken dung, sheep dung dehydration drum dryer 2



4.Working Principle of rotary dryer:

Material to be dried enters the dryer, and as the dryer rotates, the material is lifted up by a series of internal fins lining the inner wall of the dryer. When the material gets high enough to roll back off the fins, it falls back down to the bottom of the dryer, passing through the hot gas stream as it falls. This gas stream can either be moving toward the discharge end from the feed end (known as co-current flow), or toward the feed end from the discharge end (known as counter-current flow). The gas stream can be made up of a mixture of air and combustion gases from a burner, in which case the dryer is called a direct heated dryer. Alternatively, the gas stream may consist of air or another (sometimes inert) gas that is preheated. When the gas stream is preheated by some means where burner combustion gases do not enter the dryer, the dryer known as an indirect-heated type. Often, indirect heated dryers are used when product contamination is a concern.



lope(%)

rotation speed(r/min)

input temperature(º C)

motor power(kw)

output(t/h)

weight(t)

Φ 600× 6000

3-5

3-8

≤ 700

3

0.5-1.5

2.9

Φ 800× 8000

3-5

3-8

≤ 700

4

0.8-2.0

3.5

Φ 800× 10000

3-5

3-8

≤ 700

4

0.8-2.5

4.5

Φ 1000× 10000

3-5

3-8

≤ 700

5.5

1.0-3.5

5.6

Φ 1200× 10000

3-5

3-8

≤ 700

7.5

1.8-5

14.5

Φ 1200× 12000

3-5

3-8

≤ 700

11

2-6

14.8

Φ 1500× 12000

3-5

2-6

≤ 800

15

3.5-9

17.8

Φ 1800× 12000

3-5

2-6

≤ 800

18

5-12

25

Φ 2200× 12000

3-5

1.5-6

≤ 800

18.5

6-15

33

Φ 2200× 18000

3-5

1.5-6

≤ 800

22

10-18

53.8



Energy saving Cow dung, chicken dung, sheep dung dehydration drum dryer 3

Energy saving Cow dung, chicken dung, sheep dung dehydration drum dryer 4

Energy saving Cow dung, chicken dung, sheep dung dehydration drum dryer 5



Energy saving Cow dung, chicken dung, sheep dung dehydration drum dryer 6
